Activated carbon adsorption box mainly for all kinds of organic and inorganic pollutants: benzene, ketones, alcohols, ethers, alkanes and mixed organic waste gas, acid waste gas, alkaline waste gas; Suitable for pharmaceutical, smelting, chemical, machinery, electronics, electrical appliances, painting, shoemaking, rubber, plastics, printing and environmental protection desulfurization, deodorization and purification of harmful waste gas produced by various industrial production workshops.

The exhaust gas is powered by the fan, the negative pressure into the adsorption box into the activated carbon adsorption layer, because there is an unbalanced and unsaturated molecular gravity or chemical bond force on the surface of the activated carbon adsorbent, so when the surface of the activated carbon adsorbent contact with the gas, it can attract gas molecules, make it concentrated and maintain on the surface of the activated carbon, this phenomenon is called adsorption.

The adsorption capacity of activated carbon adsorbent surface is used to make the waste gas contact with the porous activated carbon adsorbent on the surface of the large surface, and the pollutants in the waste gas are adsorbed on the surface of the activated carbon, so that it is separated from the gas mixture, and the purified gas is discharged high altitude.

◎ Q235 and SUS304 material, better service life than galvanized plate
◎ Seamless full welding process, strong sealing, lower energy consumption
◎ High iodine value activated carbon, adsorption efficiency
◎ Can simultaneously treat a variety of mixed organic waste gas purification efficiency ≥95%
◎ Automatic control operation design, easy and safe operation
Fully closed type can be used indoors and outdoors, can run continuously

◎ High air volume and low concentration of organic waste gas treatment;
◎ All kinds of organic and inorganic pollutants: benzene, ketone, alcohol, ether, alkane and mixed organic waste gas, acid waste gas, alkaline waste gas;
◎ Pharmaceutical, smelting, chemical, machinery, electronics, electrical appliances, painting, shoemaking, rubber, plastics, printing and environmental protection desulfurization, deodorization and purification of harmful waste gas produced by various industrial production workshops;
◎ The eight odorous substances stipulated in the "National Odor Pollution Control Standard" : hydrogen sulfide, ammonia, trimethylamine, methylmercaptan, methylsulfide, carbon disulfide, styrene, dimethyl disulfide can be effectively removed, and the above substances are decomposed and purified.

number

Air volume

size

Velocity of flow

material

thickness

weight（kg）

LH-HTC010

10000

1800*1800*2600

1m/s

  Q235

2mm

500

LH-HTC030

30000

2100*2100*2600 2台

1m/s

  Q235

2mm

525

LH-HTC050

50000

2700*2700*2700 2台

1m/s

  Q235

2mm

1550

LH-HTC080

80000

2400*2400*2600 5台

1m/s

  Q235

2mm

7500

LH-HTC100

100000

2400*2400*2600 6台

1m/s

  Q235

2mm

9000

LH-HTC120

120000

2400*2400*2600 7台

1m/s

  Q235

2mm

10350

LH-HTC150

150000

2400*2400*2600 9台

1m/s

  Q235

2mm

13950

LH-HTC200

200000

2400*2400*2600 11台

1m/s

  Q235

2mm

17050
